型號：Y0182-00
|
ZEN: 1.01.0846.0 | WAI: | Lester: OEM NO: 9001081066, TMB066 (LUCAS), 9001081009, F000ALI1023 |
||
| No Of Teeth:11 | Rotation:CW | Length (mm):58.5 |
| Pinion O.D. (mm):30 | No Of Splines:10 | Pinion I.D. (mm):12 |
| Drive O.D. (mm):47.3 | ||
型號：Y0033-00
|
ZEN: 1.01.0745.0 | WAI: | Lester: 17756 OEM NO: 1006209584 |
||
| No Of Teeth:9 | Rotation:CW | Length (mm):53.5 |
| Pinion O.D. (mm):25.7 | No Of Splines:10 | Pinion I.D. (mm):12 |
| Drive O.D. (mm):48 | ||
型號：Y0071-00
|
ZEN: 1.01.0875.0 | WAI: 54-9157 | Lester: 17047 OEM NO: 1006209546, 1006209538, 1006209691, 9940740（FAAT） |
||
| No Of Teeth:10 | Rotation:CW | Length (mm):58.5 |
| Pinion O.D. (mm):28 | No Of Splines:10 | Pinion I.D. (mm):12 |
| Drive O.D. (mm):48 | ||
型號：Y0042-00
|
ZEN: 1.01.0729.0 | WAI: 54-9171 | Lester: 17223 OEM NO: 1006209579, 1006209917, 9001081010, TNB010 |
||
| No Of Teeth:10 | Rotation:CCW | Length (mm):77 |
| Pinion O.D. (mm):28 | No Of Splines:10 | Pinion I.D. (mm):12 |
| Drive O.D. (mm):48 | ||
型號：Q0181-00
|
ZEN: 1.01.1069.0 | WAI: 54-9197 | Lester: 17780 OEM NO: 1006209680, F1000ALI100, 1121008 |
||
| No Of Teeth:10 | Rotation:CCW | Length (mm):81 |
| Pinion O.D. (mm):28 | No Of Splines:16 | Pinion I.D. (mm):11 |
| Drive O.D. (mm):48.5 | ||
型號：Q0038-00
|
ZEN: 1.01.0308.0 | WAI: 54-9123 | Lester: 17074/17106 OEM NO: 2006209492, 2006209530, 19024520, 8122157 |
||
| No Of Teeth:9 | Rotation:CW | Length (mm):91 |
| Pinion O.D. (mm):34.8 | No Of Splines:10 | Pinion I.D. (mm):14.3 |
| Drive O.D. (mm):60 | ||
型號：Y0034-00
|
ZEN: 1.01.0925.0 | WAI: | Lester: 17730 OEM NO: 1006209638, 1006209618, 1006209677, 9947831 |
||
| No Of Teeth:9 | Rotation:CW | Length (mm):49.5 |
| Pinion O.D. (mm):25.7 | No Of Splines:10 | Pinion I.D. (mm):12 |
| Drive O.D. (mm):48 | ||
型號：Y0029-00
|
ZEN: 1.01.0799.0 | WAI: 54-9167 | Lester: 17222 OEM NO: 1006209543, 1006209585, 1006209916 |
||
| No Of Teeth:9 | Rotation:CCW | Length (mm):56 |
| Pinion O.D. (mm):25.7 | No Of Splines:10 | Pinion I.D. (mm):12 |
| Drive O.D. (mm):47.4 | ||
型號：Y0030-00
|
ZEN: 1.01.0798.0 | WAI: 54-9163 | Lester: 17023 OEM NO: 1006209535, 1006209550 |
||
| No Of Teeth:9 | Rotation:CCW | Length (mm):58.5 |
| Pinion O.D. (mm):25.7 | No Of Splines:10 | Pinion I.D. (mm):12 |
| Drive O.D. (mm):47.4 | ||
型號：Y0025-00
|
ZEN: 1.01.0482.0 | WAI: 54-9140 | Lester: 17233 OEM NO: 1006209503, 1006209504, 82GB11350AA, 1006209531 |
||
| No Of Teeth:9 | Rotation:CW | Length (mm):58.5 |
| Pinion O.D. (mm):25.7 | No Of Splines:10 | Pinion I.D. (mm):12 |
| Drive O.D. (mm):47.4 | ||
